Description
RC4WD Trail Finder 2 RTR w/1982 Toyota Pickup Hard Body Set (Blue)
This is the all new Licensed RC4WD Trail Finder 2 RTR w/1982 Toyota Pickup Hard Body Set (Blue) . This has been Officially Licensed by Toyota and is only available from RC4WD and our Dealers
The 1982 Toyota pickup truck, recognized for its timeless design, is now an exciting addition to the RC4WD 1/10 ready-to-run line-up!
This licensed RTR showcases the iconic '80s Toyota livery paint style found on full-size classic models of that era! Hit the showroom floor and open the hood to show off the 22R Engine Bay with painted parts and dress-up kit! Authentic scale details include metal emblems, fitted inner fenders, a molded interior, and a pre-installed led kit.
New suspension updates allow for better articulation out of the box, with the helper leaf springs and inner shock springs uninstalled but included for personal tuning! The shocks feature x-ring technology which reduces contact friction for smooth shaft movement while improving oil retention around the shock shaft.
The Trail Finder 2 chassis features years of trail testing and comes with innovative new features! An updated version of the Yota II front axle now includes upgraded XVDs. The leaf springs come installed under the axles, lowering the ride height and center of gravity for better stability while off-roading. The steering knuckles are improved for increased strength and durability.
Elevate your ultimate scale experience today with the impressive looks and performance of this 1/10 Toyota RTR!
1982 Toyota Pickup Hard Body
Yota 22R Engine Bay w/ Dress Up Kit
Led Basic Lighting System
Stamped Steel 1.7" Beadlock SR5 Wheels
BFGoodrich All Terrain K02 1.7" Scale Tires
The Ultimate Scale Shocks (60/80mm)
Yota II Ultimate Scale Cast Axles (XVD)
Super Soft Flex Leaf Springs
540 Crawler Brush Motor 45T
R3 Single Speed Transmission
Center Mounted Hammer Transfer Case
Twister High Torque Metal Gear Digital Servo
Outcry III Waterproof Esc
6-Cell 3000mAh NiMH Battery w/ XT60 Plug
Marlin Crawler Side Plastic Sliders V2
Rear Plastic Tube Bumper
Front Inner Fender Set
XR3 3- Channel 2.4Ghz Transmitter / Receiver Radio
Universal NiMH Peak Battery Charger
Hammer Transfer Case
Ratio: 1.47:1
Gears: Wide .8 Mod Hardened Steel Gears
Features: 8 Bearings, Cast Casing, Hardened Gears
R3 Scale Single Speed Transmission
Ratios: Pinion/Spur 14/64 = 1:4.57
Internal Ratio: 1.78:1
Gears: Wide Steel .8 Mod, Delrin Spur, Slipper Clutch
Yota II Ultimate Scale Cast Axles
Ratio: 15/40 = 2.67:1
Width at Hex: 178.2mm
Trail Finder 2 Chassis Features
Features: Billet Aluminum Construction, Adjustable Shock Hoops
Wheels
Type: Stamped Steel 1.7" Beadlock SR5 Wheels (Chrome)
Hub: 12mm Hex
Width: 23mm (0.90")
OD: 47mm (1.85")
Tires
Type: RC4WD BFGoodrich All Terrain K02 1.7" Scale Tires
Outer Diameter: 91.4mm (3.59")
Width: 34.3mm (1.35")
Inner Diameter: 43.2mm (1.70")
Trail Finder 2 Truck Dimensions
Wheelbase: 284mm (11.2")
Width: 214mm (8.4")
Height: 203mm (8.0")
Ground Clearance: 45mm (1.8")
Final Drive Ratio: 31.9:1
DRIVETRAIN
The R3 Single Speed Transmission comes with a tough cast metal case and wider gears for durability and a Delrin Spur with Slipper Clutch for performance. It also features a sturdy billet aluminum motor mount for added toughness.
The Trail Finder 2 Chassis includes the Hammer Transfer Case that features a cast metal exterior and heavy-duty .8 Mod Widened Gears, ensuring lasting functionality.
Drawing on the success of the RC4WD MOA Gear Sets, the Trail Finder 2 Chassis has the most durable gears RC4WD has to offer, capable of staying on the trail day after day.
The most scale accurate axles on the market, the RC4WD Yota II Ultimate Scale Cast Axles (XVD) feature innovative 8 degree round knuckles, unique removable diff covers, lower mounting points and a compact offset pumpkin in the front.
The driveshafts found on the Trail Finder 2 Chassis feature heavy-duty uni-joint metal shafts for great driveline angles and durability on the trail.
SUSPENSION
The shocks feature X-ring technology which reduces contact friction for smooth shaft movement while improving oil retention around the shock shaft.
The Trail Finder 2 Chassis includes a set of RC4WD Ultimate Scale Shocks. These ultimate scale shock absorbers offer realistic looks and performance. They are machined from billet aluminum with internal springs and rebuildable internal parts!
With strength in mind, the ladder frame design of the Trail Finder 2 Chassis is made with CNC machined, billet aluminum and comes with scale shock hoops, a chassis servo mount, and transmission and transfer case mounts.
Every RTR needs a tough set of tires to hit the trails and the included RC4WD BFGoodrich All Terrain K02 1.7" Scale Tires deliver the perfect amount of traction with its advanced X2S3 soft and sticky compound. The scale details complete the look in just the right size.
DETAILS
This 1982 Toyota Pickup model features an impressive display of scale details including mirrors, door handles, vents, front grille, and more!
The body is constructed of durable hard plastic with a classic shape that replicates the full-size model with accuracy and authenticity.
This 1982 Toyota Pickup features a fully molded 22R engine bay as well as a dress-up kit that brings out the details and makes this classic model stand out!
This 1982 Toyota Pickup interior cab features durable molded hard plastic that matches the full-size vehicle. Air vents, steering wheel, and shift knob are all present to show the realism! Go ahead and pack in your driver model to further enhance the look!
The preinstalled ultra-bright LED kit illuminates the trail and keeps the action going long after the sun sets! This blend of stunning realism and functionality is optimal for night adventures!
ELECTRONICS
Straight out of the box, an LED light set comes professionally installed and out of sight, keeping that realistic look.
The Trail Finder 2 Chassis is powered by the tough and durable RC4WD 45 Turn Crawler Motor. With long-lasting performance at its core, this power machine is tuned for rock climbing and scale driving!
Included is the popular RC4WD Outcry III Waterproof ESC Brushed Speed Controller, with built-in drag brake, for reliable constant power on demand at any time!
With a massive 277.6oz@6V of torque and a full metal geared drivetrain, the RC4WD Twister Metal Gear Digital Servo has the power and performance needed to outmaneuver and overcome tough terrain.
It's ALL in the box! Everything you need is provided to get you on the trails today!
What's Included:
- 1x RC4WD Trail Finder 2 RTR w/1982 Toyota Pickup Hard Body Set (Blue)
