Description
MODEL SPECS
Name: Maxx Slash Type: Short Course Truck Speed: 70+ mph with Dual 3S LiPo batteries and optional pinion gear (sold separately) Skill Level: 4 Scale: 1/8 Weight: 10.34 pounds (4.69 kg) Length: 26.5 inches (674 mm) Width: 14.3 inches (363 mm) Front Track: 14.3 inches (363 mm) Rear Track: 14.3 inches (363 mm) Height: 9.64 inches (245 mm) MOTOR SPECS
Name: 4-pole 2000 Kv Type: Sensorless brushless Weight: 14.32 oz (406 g) Length: 2.97 inches (76 mm) Diameter: 1.65 inches (42 mm) Shaft Size: 5 mm Connector Type: Traxxas 6.5 mm bullet connectors ESC SPECS
Name: VXL-6s Type: Brushless Case Size: 2.28” (58 mm) x 2.83” (72 mm) x 1.81” (46 mm) Weight: 7.30 oz (207 g) Motor Connectors: 6.5 mm bullet connectors Battery Connectors: Traxxas High-Current Connectors - VXL-6s™ Waterproof Electronic Speed Control
- 6S LiPo compatible
- Integrated cooling fan
- Real-time telemetry via Traxxas Link™
- 3-LED status indicators
- Powered accessory ports
- 10-gauge silicone wire
- Integrated protection circuits
- Velineon® Brushless Motor
- 4-pole 2000 Kv
- 5 mm output shaft
- Finned can for better heat dissipation
- Fixed-Mesh Motor Cradle
- Supports entire motor length
- Reduces flex for longer gear life
- 70+ mph with Optional Gearing and Two 3S LiPo Batteries (sold separately)
- Traxxas Stability Management®
- Improves straight line acceleration and braking on low-traction surfaces
- Never dulls throttle or slows the truck
- Adjusts from off to 100% assistance from the transmitter
- TQi™ 2.4 GHz High Output Radio System
- TQi 2-channel transmitter
- Traxxas Link enabled
- 2.4 GHz 5-channel micro receiver (6533) with fail-safe security and integrated telemetry ports
- Automatically stores and loads settings for up to 30 Traxxas Link-enabled models—just switch on and drive, “model selection” is not required
- Programmable Multi-Function knob
- Adjustable steering and throttle percentage (dual rates)
- Adjustable steering and throttle sensitivity (exponential)
- Adjustable steering and throttle end points
- Clipless Body
- Quick and secure installation and removal
- Managed airflow for improved high-speed stability
- Rigid internal frame
- Additional nerf bar side support
- Eliminates body posts and clips
- Molded body reinforcements for tear-through protection
- Driveline
- Full-time shaft-driven 4-wheel drive
- Torque-Biasing Center Drive
- Absorbs shocks and distributes power
- Aluminum housing
- Sealed, silicone fluid-filled diffs with large module ring and pinion gears
- Steel pinion and spur gear
- Heavy-duty Cush Drive™
- Steel-Core hybrid telescoping driveshafts
- Splined aluminum center driveshaft
- Modular Low-CG Composite Chassis
- Extended modular chassis design interlocks with front and rear bulkheads
- Absorbs and distributes impact energy
- Molded-in hex reinforcements on flat surfaces
- Easy to service and access components
- Driveline is sealed in the chassis to keep out dirt and grit
- Easy Battery Access
- Large battery compartment with secure snap-lock battery door
- Accepts single 6700 mAh 4-cell LiPo battery or dual 5000 mAh 3S LiPo batteries
- Batteries are protected deep in the chassis
- More secure than conventional retention systems
- Heavy-Duty Steering Bellcranks and Servo
- Large-scale high-output steering servo
- 285 oz-in of torque
- 0.18 sec transit speed
- Triangulated mounting system to fully support case
- Heavy-duty double-shear bellcranks
- Suspension
- Heavy duty double-shear suspension arms
- Tough composite formula resists impact damage, even in cold weather
- Engineered to optimize suspension travel and steering angles
- All critical suspension points have double shear strength
- Steel pivot balls
- C-hub and steering block geometry maximizes steering angle
- Fixed, high-strength camber and toe links
- Steel upper and lower tie bars
- GT-Maxx® Shocks
- Machined aluminum threaded body
- Extra-large bore and capacity
- Large-diameter damper shaft
- Lower seal cartridge with dual X-rings
- Adjustable upper spring retainer
- Plastic shock caps with pivot balls
- Lower spring perches bolted on
- Bumpers
- Heavy duty energy absorbing front and rear bumpers
- Lower front and rear skids for impact and abrasion resistance
- Integrated nerf bars for side impact resistance
- Adjustable wheelie bar with integrated carry handle
- Wheels & Tires
- Tough dual-profile wheels with keyed 17 mm hex receptor
- Large 5.3″ Maxx SC belted tires
- Limits tire expansion for game-changing performance
- 1-piece foam inserts
- Pre-glued and ready for action
MODEL 102076-4: Maxx Slash® 4WD 6S brushless short course truck. Fully assembled, Ready-To-Race®, with TQi™ 2.4 GHz radio system, VXL-6s brushless power system, and ProGraphix® clipless body.What’s In The Box:
- Maxx Slash, Ready-To-Race short course truck with 2000 Kv brushless motor
- VXL-6s waterproof electronic speed control with integrated telemetry
- Quick Start Guide
- TQi 2.4 GHz radio system
- High quality maintenance tools
- Jumper plug (for 4S battery use)
What You’ll Need:
- LiPo Batteries
Traxxas recommends dual 5000 mAh 3-cell 11.1 V Power Cell LiPo batteries for maximum performance. Dual 7600 mAh 7.4 V LiPo batteries or a single 6700 mAh 14.8 V LiPo battery will operate the vehicle with reduced performance. NiMH batteries are not supported.
- LiPo Balance Charger with iD®
- AA Alkaline Batteries
Four AA alkaline batteries for the transmitter.
Description
MODEL SPECS
| Name: | Maxx Slash |
|---|---|
| Type: | Short Course Truck |
| Speed: | 70+ mph with Dual 3S LiPo batteries and optional pinion gear (sold separately) |
| Skill Level: | 4 |
| Scale: | 1/8 |
| Weight: | 10.34 pounds (4.69 kg) |
| Length: | 26.5 inches (674 mm) |
| Width: | 14.3 inches (363 mm) |
| Front Track: | 14.3 inches (363 mm) |
| Rear Track: | 14.3 inches (363 mm) |
| Height: | 9.64 inches (245 mm) |
MOTOR SPECS
| Name: | 4-pole 2000 Kv |
|---|---|
| Type: | Sensorless brushless |
| Weight: | 14.32 oz (406 g) |
| Length: | 2.97 inches (76 mm) |
| Diameter: | 1.65 inches (42 mm) |
| Shaft Size: | 5 mm |
| Connector Type: | Traxxas 6.5 mm bullet connectors |
ESC SPECS
| Name: | VXL-6s |
|---|---|
| Type: | Brushless |
| Case Size: | 2.28” (58 mm) x 2.83” (72 mm) x 1.81” (46 mm) |
| Weight: | 7.30 oz (207 g) |
| Motor Connectors: | 6.5 mm bullet connectors |
| Battery Connectors: | Traxxas High-Current Connectors |
- VXL-6s™ Waterproof Electronic Speed Control
- 6S LiPo compatible
- Integrated cooling fan
- Real-time telemetry via Traxxas Link™
- 3-LED status indicators
- Powered accessory ports
- 10-gauge silicone wire
- Integrated protection circuits
- Velineon® Brushless Motor
- 4-pole 2000 Kv
- 5 mm output shaft
- Finned can for better heat dissipation
- Fixed-Mesh Motor Cradle
- Supports entire motor length
- Reduces flex for longer gear life
- 70+ mph with Optional Gearing and Two 3S LiPo Batteries (sold separately)
- Traxxas Stability Management®
- Improves straight line acceleration and braking on low-traction surfaces
- Never dulls throttle or slows the truck
- Adjusts from off to 100% assistance from the transmitter
- TQi™ 2.4 GHz High Output Radio System
- TQi 2-channel transmitter
- Traxxas Link enabled
- 2.4 GHz 5-channel micro receiver (6533) with fail-safe security and integrated telemetry ports
- Automatically stores and loads settings for up to 30 Traxxas Link-enabled models—just switch on and drive, “model selection” is not required
- Programmable Multi-Function knob
- Adjustable steering and throttle percentage (dual rates)
- Adjustable steering and throttle sensitivity (exponential)
- Adjustable steering and throttle end points
- Clipless Body
- Quick and secure installation and removal
- Managed airflow for improved high-speed stability
- Rigid internal frame
- Additional nerf bar side support
- Eliminates body posts and clips
- Molded body reinforcements for tear-through protection
- Driveline
- Full-time shaft-driven 4-wheel drive
- Torque-Biasing Center Drive
- Absorbs shocks and distributes power
- Aluminum housing
- Sealed, silicone fluid-filled diffs with large module ring and pinion gears
- Steel pinion and spur gear
- Heavy-duty Cush Drive™
- Steel-Core hybrid telescoping driveshafts
- Splined aluminum center driveshaft
- Modular Low-CG Composite Chassis
- Extended modular chassis design interlocks with front and rear bulkheads
- Absorbs and distributes impact energy
- Molded-in hex reinforcements on flat surfaces
- Easy to service and access components
- Driveline is sealed in the chassis to keep out dirt and grit
- Easy Battery Access
- Large battery compartment with secure snap-lock battery door
- Accepts single 6700 mAh 4-cell LiPo battery or dual 5000 mAh 3S LiPo batteries
- Batteries are protected deep in the chassis
- More secure than conventional retention systems
- Heavy-Duty Steering Bellcranks and Servo
- Large-scale high-output steering servo
- 285 oz-in of torque
- 0.18 sec transit speed
- Triangulated mounting system to fully support case
- Heavy-duty double-shear bellcranks
- Suspension
- Heavy duty double-shear suspension arms
- Tough composite formula resists impact damage, even in cold weather
- Engineered to optimize suspension travel and steering angles
- All critical suspension points have double shear strength
- Steel pivot balls
- C-hub and steering block geometry maximizes steering angle
- Fixed, high-strength camber and toe links
- Steel upper and lower tie bars
- GT-Maxx® Shocks
- Machined aluminum threaded body
- Extra-large bore and capacity
- Large-diameter damper shaft
- Lower seal cartridge with dual X-rings
- Adjustable upper spring retainer
- Plastic shock caps with pivot balls
- Lower spring perches bolted on
- Bumpers
- Heavy duty energy absorbing front and rear bumpers
- Lower front and rear skids for impact and abrasion resistance
- Integrated nerf bars for side impact resistance
- Adjustable wheelie bar with integrated carry handle
- Wheels & Tires
- Tough dual-profile wheels with keyed 17 mm hex receptor
- Large 5.3″ Maxx SC belted tires
- Limits tire expansion for game-changing performance
- 1-piece foam inserts
- Pre-glued and ready for action
MODEL 102076-4: Maxx Slash® 4WD 6S brushless short course truck. Fully assembled, Ready-To-Race®, with TQi™ 2.4 GHz radio system, VXL-6s brushless power system, and ProGraphix® clipless body.
What’s In The Box:
- Maxx Slash, Ready-To-Race short course truck with 2000 Kv brushless motor
- VXL-6s waterproof electronic speed control with integrated telemetry
- Quick Start Guide
- TQi 2.4 GHz radio system
- High quality maintenance tools
- Jumper plug (for 4S battery use)
What You’ll Need:
- LiPo Batteries
Traxxas recommends dual 5000 mAh 3-cell 11.1 V Power Cell LiPo batteries for maximum performance. Dual 7600 mAh 7.4 V LiPo batteries or a single 6700 mAh 14.8 V LiPo battery will operate the vehicle with reduced performance. NiMH batteries are not supported.
- LiPo Balance Charger with iD®
- AA Alkaline Batteries
Four AA alkaline batteries for the transmitter.
